Description
Illuminate the Wild with PROJECT X Series X High Power LED Lights
Get ready to connect with the wild using the PROJECT X Series X High Power LED auxiliary lights.
These lights are expertly engineered with Osram LED technology, allowing them to cut through the darkness and illuminate the trail ahead. Moreover, with a powerful combo beam, they produce 165 watts of pure white light (5700K) in a broad, penetrating beam. Thanks to the integrated Active Thermal Management System (ATMS), the HP.85 can run harder for longer, making it perfect for the toughest conditions.
Qualifies for free shipping
Unmatched Performance with Osram LEDs
-
5-Watt High Power Osram LEDs – The Osram-LEDs deliver 165W of pure white light at 5700K, ensuring maximum illumination in all conditions. As a result, these LEDs are both bright and efficient.
- Best-in-Class Power – With 21,780 raw lumens (15,410 effective) per light, you get outstanding brightness that provides excellent visibility even in the darkest environments. This makes them ideal for off-road adventures or nighttime driving.
Superior Optics for Maximum Beam Control
- Highly Polished Reflector – The super-efficient aluminum metalized reflector uses precisely scalloped parabolas, which provide ultimate beam control and optimal performance. Therefore, the light is directed exactly where you need it, reducing light waste and improving efficiency.
LED Front Position Light for Enhanced Safety
- Signature Built-In LED Light – The built-in LED light meets ECE requirements for front position lights, improving daytime visibility and safety. Furthermore, this feature helps to make your vehicle more visible to others, especially in low-light conditions.
Customizable and Adaptable Design
-
Customizable Appearance – Personalize your Series X HP.85 lights with your choice of three inner trim pieces: Brocky Blue, Dragon Red, or Project X Green. As a result, you can choose the look that best matches your vehicle’s style.
- Unique Fit & Adjustment – The tool-free vertical adjustment allows for on-the-fly beam corrections using the ergonomic adjuster knob. In addition, the mounting system utilizes polyurethane bushings, suspending the light and making it impervious to shock and vibration. Consequently, this provides increased reliability over time.
Engineered for Durability and Longevity
-
Built to Last – Constructed from lightweight, super-strong Pressure Die Cast Aluminum, these lights provide rugged durability and uncompromised strength in harsh environments. Therefore, you can rely on them for long-term performance.
- Protected from the Elements – Fully sealed against water and dust intrusion (IP66 & IP67-rated), these lights feature a genuine Gore-Tex® breather vent and integrated Deutsch® connectors for a secure power connection. This ensures reliable performance in any weather.
Durable Lens Design for Ultimate Protection
- Virtually Unbreakable Lens – Featuring a hard-coated, UV-resistant polycarbonate lens, these lights are designed to provide rock and debris protection. Therefore, they stay in top condition, even under the harshest conditions.
- Beam Length (1 lamp): 1 lux @ 2536 Feet
- Beam Length (2 lamps): 1 lux @ 3585 Feet
- Beam Width (1 lamp): 1 lux @ 67 Feet
- Beam Width (2 lamps): 1 lux @ 285 Feet
- Bezel Color: ?Brocky? Blue, ?Dragon? Red and ?PROJECT X? Green
- Bulb Quantity: 33
- Bulb Technology: LED
- Bulb Type: Osram LEDs
- Color Rendering Index: 72
- Connector Gender: Male
- Connector Quantity: 1
- Connector Type: Deutsch DT 3-pin
- EMC: ECE R10
- Effective Lumens: 15410
- Hardware Included: Yes
- Hardware Material: Stainless Steel
- Heat Management: Active Thermal Management System
- Height: 9.3 IN.
- Housing Color: Black
- Housing Finish: Flat
- Housing Material: Pressure die-cast aluminum
- IP Rating: IP67
- Input Voltage Range: 9 - 33V DC
- Lamp Current Draw @ 12V: 12.5 Amps
- Length: 8.5 IN.
- Lens Color: Clear
- Lens Diameter: 8.5 IN.
- Lens Material: Hard coated Polycarbonate
- Light Color Temperature: 5700 K
- Mounting Hole Quantity: 3
- Operating Temp: -40?F to 149?F
- Positional Light Current Draw @ 12V: 0.17 Amps
- Protection: Reverse Polarity Protection
- Raw Lumens: 21780
- Shape: Round
- Universal Or Specific Fit: Universal
- Wattage Draw @ 12V DC: Driving Light - 173 Watts, Position - 1.6 Watts
- Weight: 7.05 LBS
- Width: 4.4 IN.
- Wire Quantity: 3
- Wiring Harness Included: Y
