Connect with the Wild with PROJECT X Series X High Power LED Lights
Get ready to illuminate the trail with the PROJECT X Series X High Power LED auxiliary lights. These lights are engineered for unmatched performance, utilizing Osram LED technology to cut through darkness and light the way ahead. Featuring an integrated Active Thermal Management System (ATMS), the HP.70 delivers 120 watts of pure white light (5700K) in a broad, penetrating beam that lights the path ahead.
Qualifies for free shipping
Unparalleled Performance with Osram LEDs
✔ Powerful 5-Watt Osram LEDs – These lights deliver 120W of pure white light (5700K), offering bright, clear illumination for any adventure.
✔ Best-in-Class Power – With 15,000 raw lumens (8889 effective) per light, these lights provide exceptional brightness and optimal visibility in all conditions.
Superior Optics for Maximum Control
✔ Highly Polished Reflector – The super-efficient aluminum metalized reflector uses precisely scalloped parabolas for ultimate beam control and performance. This ensures the light is focused exactly where you need it.
LED Front Position Light for Added Safety
✔ Signature LED Front Position Light – The built-in LED light meets ECE requirements, improving daytime driving visibility and safety on the road.
Customization and Fit for Your Vehicle
✔ Customizable Appearance – Choose from three inner trim pieces to personalize your Series X HP.70 lights: Brocky Blue, Dragon Red, or Project X Green.
✔ Unique Fit & Adjustment – The tool-free vertical adjustment allows for on-the-fly beam correction using an ergonomic adjuster knob. Additionally, the mounting system utilizes polyurethane bushings, suspending the light to make it impervious to shock and vibration.
Engineered for Durability
✔ Built to Last – Constructed from lightweight, super-strong Pressure Die Cast Aluminum, the housing offers uncompromised strength and rugged durability for any environment.
Protected from the Elements
✔ Sealed Against the Elements – These lights are fully sealed against water and dust with an IP66 & IP67 rating, ensuring reliable performance in harsh conditions. They also feature a genuine Gore-Tex® breather vent and integrated Deutsch® connectors for a secure power connection.
Durable Lens Design
✔ Virtually Unbreakable Lens – The hard-coated, UV-resistant polycarbonate lens is built to withstand rocks, debris, and harsh conditions, offering ultimate protection for your lights.
- Beam Length (1 lamp): 1 lux @ 1886 Feet
- Beam Length (2 lamps): 1 lux @ 2664 Feet
- Beam Width (1 lamp): 1 lux @ 147 Feet
- Beam Width (2 lamps): 1 lux @ 206 Feet
- Bezel Color: ?Brocky? Blue, ?Dragon? Red and ?PROJECT X? Green
- Bulb Quantity: 24
- Bulb Technology: LED
- Bulb Type: Osram LEDs
- Color Rendering Index: 72
- Connector Gender: Male
- Connector Quantity: 1
- Connector Type: Deutsch DT 3-pin
- EMC: ECE R10
- Effective Lumens: 8889
- Grade Type: Heavy Duty
- Hardware Included: Yes
- Hardware Material: Stainless Steel
- Heat Management: Active Thermal Management System
- Height: 7.8 IN.
- Housing Color: Black
- Housing Finish: Flat
- Housing Material: Pressure die-cast aluminum
- IP Rating: IP67
- Input Voltage Range: 9 - 33V DC
- Lamp Current Draw @ 12V: 8.77 Amps
- Length: 7
- Lens Color: Clear
- Lens Diameter: 7 Inch
- Lens Material: Hard coated Polycarbonate
- Light Color Temperature: 5700 K
- Mounting Hole Quantity: 3
- Operating Temp: -40?F to 149?F
- Positional Light Current Draw @ 12V: 0.17 Amps
- Protection: Reverse Polarity Protection
- Raw Lumens: 15000
- Shape: Round
- Universal Or Specific Fit: Universal
- Wattage Draw @ 12V DC: Driving Light - 106 Watts, Position - 2.2 Watts
- Weight: 3.85 LBS
- Width: 4
- Wire Quantity: 3
- Wiring Harness Included: Y
