Description
Illuminate the Wild with PROJECT X Series One Free Form LED Lights
Connect with the wild using the PROJECT X Series One Free Form LED auxiliary lights. These lights feature enhanced free-form optics to capture and focus more light, delivering a greater penetrating beam down the road. This unique design eliminates wasted light, ensuring the beam is focused precisely where you need it most. Whether you need a focused beam for distance or a wide coverage, the Series One is available in both Spot and Flood beams.
Qualifies for free shipping
Powered by Cree® Technology for Maximum Efficiency
✔ Powered by Cree® – The Cree® XHP50.2 LED chip sets deliver extremely efficient, powerful 5000K white light output. This ensures optimal visibility in all conditions.
✔ HID Performance in LED Form – With 5,700 raw lumens (2,500 effective) per light, you get intense, high-performance lighting in a compact LED package.
Superior Optics for Improved Visibility
✔ Enhanced Free-Form Optics – These lights use advanced optics to focus more of the light generated by the LEDs, creating a greater penetrating light output. This focused beam improves visibility down the road, eliminating wasted light for more efficient illumination.
Customizable and Convenient Features
✔ LED Front Position Light Pipe – The built-in LED light pipe improves daytime driving visibility and meets ECE requirements for front position lights, enhancing safety.
✔ Customizable Appearance – Tailor your Series One FF.90 lights with two glare shield caps available in Black or Project X Green. This lets you match the lights to your vehicle’s aesthetic.
Durable, Reliable, and Weather-Proof
-
Unique Fit & Adjustment – The heavy-duty, multi-position bracket offers multiple mounting positions, ensuring a perfect fit for your vehicle.
-
Engineered to Survive – Constructed with Fiber Reinforced Polymer, these lights have a super strong, impact-resistant housing, built to endure tough environments.
-
Protected from the Elements – With an IP67 rating, these lights are fully sealed against water and dust, ensuring they perform reliably in any weather. Additionally, the integrated Deutsch® connector provides a secure power connection.
- Durable Lens Design – The hard-coated, UV-resistant polycarbonate lens is virtually unbreakable, providing rock and debris protection for tough environments.
- Beam Length (1 lamp): 1 lux @ 1574 Feet
- Beam Length (2 lamps): 1 lux @ 2230 Feet
- Beam Width (1 lamp): 1 lux @ 78 Feet
- Beam Width (2 lamps): 1 lux @ 206 Feet
- Bezel Color: Black and ?PROJECT X? Green
- Bulb Quantity: 3
- Bulb Technology: LED
- Bulb Type: 15W XHP50.2, Cree LEDs
- Color Rendering Index: 70
- Connector Gender: Male
- Connector Quantity: 1
- Connector Type: Deutsch DT 3-pin
- EMC: ECE R10
- Effective Lumens: 2500
- Hardware Included: Yes
- Hardware Material: Stainless Steel
- Heat Management: Active Thermal Management System
- Height: 9.8 IN.
- Housing Color: Black
- Housing Finish: Matte
- Housing Material: Fiber Reinforced Polymer
- IP Rating: IP67
- Input Voltage Range: 9 - 33V DC
- Lamp Current Draw @ 12V: 4.9 Amps
- Length: 9
- Lens Color: Clear
- Lens Diameter: 9
- Lens Material: Hard coated Polycarbonate
- Light Color Temperature: 5000 K
- Mounting Hole Quantity: 2
- Operating Temp: -40?F to 149?F
- Positional Light Current Draw @ 12V: 0.13 Amps
- Protection: Reverse Polarity Protection
- Raw Lumens: 5700
- Shape: Round
- Universal Or Specific Fit: Universal
- Wattage Draw @ 12V DC: Driving Light - 62 Watts, Position - 1.8 Watts
- Weight: 4.85 LBS
- Width: 5.3 IN.
- Wire Quantity: 3
- Wiring Harness Included: Y
