Project X FF.90 Flood Light

Illuminate the Wild with PROJECT X Series One Free Form LED Lights

Get ready to connect with the wild using the PROJECT X Series One Free Form LED auxiliary lights. These lights feature enhanced free-form optics, which capture and focus more of the light generated by the LEDs. As a result, they produce a stronger, more penetrating light output down the road, focusing the beam where you need it most and eliminating wasted light.

Qualifies for free shipping

Whether you're on the highway or off-road, these lights are available in Spot and Flood beams, providing you with flexibility for any environment.

Powerful Performance with Cree® Technology

✔ Powered by Cree® – The Cree® XHP50.2 LED chip sets deliver exceptionally efficient and powerful 5000K white light output, ensuring optimal brightness in all conditions.
✔ HID Performance in LED Form – With 5,700 raw lumens (2,500 effective) per light, you get HID-like intensity with the efficiency of LED technology.

Superior Optics for Maximum Visibility

✔ Enhanced Free Form Optics – The Series One lights utilize advanced optics that capture and focus more of the light generated by the LEDs. This results in a greater penetrating light output, giving you enhanced visibility down the road. Moreover, it eliminates wasted light, focusing the beam exactly where you need it.

Added Features for Safety and Customization

✔ LED Front Position Light Pipe – The built-in LED light pipe not only improves daytime visibility but also meets ECE requirements, increasing your safety on the road.
✔ Customizable Appearance – Personalize the look of your Series One FF.90 lights by choosing from two glare shield caps: Black or Project X Green. This ensures that your lights match your vehicle’s style.

Built for Durability and Performance

• Unique Fit and Adjustment – The heavy-duty, multi-position bracket allows for multiple mounting positions, ensuring a perfect fit for any vehicle.

• Engineered to Survive – Constructed with Fiber Reinforced Polymer, these lights feature super strong, impact-resistant housing designed to withstand tough environments.

• Protected from the Elements – With an IP67 rating, these lights are fully sealed against water and dust. Additionally, they use an integrated Deutsch® connector for a secure power connection.

• Durable Lens Design – Featuring a hard-coated, UV-resistant polycarbonate lens, these lights provide virtually unbreakable protection against rocks, debris, and other harsh conditions.



• Beam Length (1 lamp): 1 lux @ 1574 Feet
• Beam Length (2 lamps): 1 lux @ 2230 Feet
• Beam Width (1 lamp): 1 lux @ 78 Feet
• Beam Width (2 lamps): 1 lux @ 206 Feet
• Bezel Color: Black and ?PROJECT X? Green
• Bulb Quantity: 3
• Bulb Technology: LED
• Bulb Type: 15W XHP50.2, Cree LEDs
• Color Rendering Index: 70
• Connector Gender: Male
• Connector Quantity: 1
• Connector Type: Deutsch DT 3-pin
• EMC: ECE R10
• Effective Lumens: 2500
• Hardware Included: Yes
• Hardware Material: Stainless Steel
• Heat Management: Active Thermal Management System
• Height: 9.8 IN.
• Housing Color: Black
• Housing Finish: Matte
• Housing Material: Fiber Reinforced Polymer
• IP Rating: IP67
• Input Voltage Range: 9 - 33V DC
• Lamp Current Draw @ 12V: 4.9 Amps
• Length: 9
• Lens Color: Clear
• Lens Diameter: 9
• Lens Material: Hard coated Polycarbonate
• Light Color Temperature: 5000 K
• Mounting Hole Quantity: 2
• Operating Temp: -40?F to 149?F
• Positional Light Current Draw @ 12V: 0.13 Amps
• Protection: Reverse Polarity Protection
• Raw Lumens: 5700
• Shape: Round
• Universal Or Specific Fit: Universal
• Wattage Draw @ 12V DC: Driving Light - 62 Watts, Position - 1.8 Watts
• Weight: 4.85 LBS
• Width: 5.3 IN.
• Wire Quantity: 3
• Wiring Harness Included: Y
