Connect with the Wild – PROJECT X Series One Free Form LED Lights
Get ready to illuminate the wild with PROJECT X Series One Free Form LED auxiliary lights. These lights are engineered with enhanced free-form optics to capture and focus more light produced by the LEDs. As a result, they generate a greater penetrating light output, ensuring the beam focuses exactly where you need it. Additionally, they are available in both Spot and Flood beam options, giving you versatility for every driving situation.
Qualifies for free shipping
Powerful Performance with Cree Technology
-
Powered by Cree® – The latest Cree® XHP50.2 LED chip sets provide an extremely efficient and powerful 5000K white light output. This enables clear and bright illumination in all environments.
- HID-Level Performance in an LED Package – With 3,800 raw lumens (1,663 effective) per light, you’ll enjoy HID-like intensity while benefiting from the efficiency of LED technology.
Superior Optics for Maximum Visibility
Enhanced Free Form Optics – Thanks to advanced free-form optics, the Series One lights capture and focus more of the light produced by the LEDs. This results in a greater penetrating beam that eliminates wasted light, improving your visibility down the road. Consequently, you can see farther, ensuring safer driving, especially in off-road conditions.
Added Features for Safety and Customization
-
LED Front Position Light Pipe – The built-in LED light pipe not only improves daytime visibility but also meets ECE requirements, enhancing your vehicle’s overall safety on the road.
- Customizable Appearance – You can easily personalize your Series One FF.70 lights with your choice of two glare shield caps in Black or Project X Green. This allows you to match the lights to your style.
Built for Durability and Performance
-
Unique Fit and Adjustment – The multi-position heavy-duty bracket offers multiple mounting positions, guaranteeing a perfect fit for any vehicle.
-
Engineered to Survive – Constructed from Fiber Reinforced Polymer, the housing is super strong, impact-resistant, and able to withstand even the toughest environments.
-
Protected from the Elements – These lights are fully sealed (IP67-rated) against water and dust, providing reliable protection regardless of the weather conditions. In addition, the integrated Deutsch® connector ensures a secure power connection at all times.
- Durable Lens Design – The hard-coated, UV-resistant polycarbonate lens is virtually unbreakable, providing excellent rock and debris protection, so you can trust these lights in harsh conditions.
- Add-On: AC538806-1
- Beam Length (1 lamp): 1 lux @ 1443 Feet
- Beam Length (2 lamps): 1 lux @ 2034 Feet
- Beam Width (1 lamp): 1 lux @ 147 Feet
- Beam Width (2 lamps): 1 lux @ 206 Feet
- Bezel Color: Black and ?PROJECT X? Green
- Bulb Quantity: 2
- Bulb Technology: LED
- Bulb Type: 15W XHP50.2, Cree LEDs
- Color Rendering Index: 70
- Connector Gender: Male
- Connector Quantity: 1
- Connector Type: Deutsch DT 3-pin
- EMC: ECE R10
- Effective Lumens: 1663
- Hardware Included: Yes
- Hardware Material: Stainless Steel
- Heat Management: Active Thermal Management System
- Height: 7.7 IN.
- Housing Color: Black
- Housing Finish: Matte
- Housing Material: Fiber Reinforced Polymer
- IP Rating: IP67
- Input Voltage Range: 9 - 33V DC
- Lamp Current Draw @ 12V: 3.32 Amps
- Length: 7
- Lens Color: Clear
- Lens Diameter: 7
- Lens Material: Hard coated Polycarbonate
- Light Color Temperature: 5000 K
- Mounting Hole Quantity: 2
- Operating Temp: -40?F to 149?F
- Positional Light Current Draw @ 12V: 0.13 Amps
- Protection: Reverse Polarity Protection
- Raw Lumens: 3800
- Shape: Round
- Universal Or Specific Fit: Universal
- Wattage Draw @ 12V DC: Driving Light - 39 Watts, Position - 1.8 Watts
- Weight: 2.42 LBS
- Width: 4.1 IN.
- Wire Quantity: 3
- Wiring Harness Included: Y
