Illuminate the Wild with PROJECT X Series One Free Form LED Lights
Take your lighting to the next level with PROJECT X Series One Free Form LED lights. These lights utilize enhanced free-form optics, allowing them to maximize light output and direct the beam exactly where it’s needed. As a result, you get a stronger, more concentrated beam that cuts through the darkness.
Qualifies for free shipping
Furthermore, these lights are available in both Spot and Flood beam options, which means you can easily customize your setup to meet your specific needs. Whether you're cruising down open highways or navigating rugged trails, these lights will ensure maximum visibility and safety.
Unmatched LED Performance
-
Powered by Cree® LEDs – The Cree® XHP50.2 LED chip delivers a powerful, efficient 5000K white light that increases visibility in any condition.
-
HID-Level Performance – With 3,800 raw lumens (1,663 effective), these lights provide high-intensity illumination that competes with HID systems.
-
Precision Beam Control – Thanks to enhanced free-form optics, these lights focus more usable light directly down the road, eliminating wasted output and improving visibility.
- LED Position Light Pipe – The built-in LED light pipe not only improves daytime visibility but also meets ECE regulations for added safety.
Built for the Toughest Conditions
-
Advanced Heat Management – With the Active Thermal Management System (ATMS), the FF.70 can run longer without overheating, ensuring consistent performance.
-
Customizable Appearance – You can personalize the look of your lights with your choice of two glare shield caps in Black or Project X Green to fit your style.
-
Versatile Mounting Options – The heavy-duty, multi-position bracket ensures a perfect fit on your vehicle, no matter the make or model.
-
Durable Construction – Built from Fiber Reinforced Polymer, these lights are designed to be impact-resistant and ready for even the toughest environments.
-
Weatherproof Design – With an IP67 rating, the lights are fully sealed against water and dust, ensuring reliable performance in any weather.
Indestructible Lens – The UV-resistant, hard-coated polycarbonate lens offers exceptional protection against rocks, debris, and harsh conditions, making them virtually unbreakable.
Why Choose PROJECT X Series One?
By combining cutting-edge LED technology, superior optics, and rugged durability, these lights provide unmatched performance. Whether you are off-roading, navigating tricky terrain, or improving visibility on the highway, the PROJECT X Series One ensures that you are always prepared.
- Beam Length (1 lamp): 1 lux @ 1443 Feet
- Beam Length (2 lamps): 1 lux @ 2034 Feet
- Beam Width (1 lamp): 1 lux @ 147 Feet
- Beam Width (2 lamps): 1 lux @ 206 Feet
- Bezel Color: Black and ?PROJECT X? Green
- Bulb Quantity: 2
- Bulb Technology: LED
- Bulb Type: 15W XHP50.2, Cree LEDs
- Color Rendering Index: 70
- Connector Gender: Male
- Connector Quantity: 1
- Connector Type: Deutsch DT 3-pin
- EMC: ECE R10
- Effective Lumens: 1663
- Hardware Included: Yes
- Hardware Material: Stainless Steel
- Heat Management: Active Thermal Management System
- Height: 7.7 IN.
- Housing Color: Black
- Housing Finish: Matte
- Housing Material: Fiber Reinforced Polymer
- IP Rating: IP67
- Input Voltage Range: 9 - 33V DC
- Lamp Current Draw @ 12V: 3.32 Amps
- Length: 7
- Lens Color: Clear
- Lens Diameter: 7
- Lens Material: Hard coated Polycarbonate
- Light Color Temperature: 5000 K
- Mounting Hole Quantity: 2
- Operating Temp: -40?F to 149?F
- Positional Light Current Draw @ 12V: 0.13 Amps
- Protection: Reverse Polarity Protection
- Raw Lumens: 3800
- Shape: Round
- Terminal Quantity: 1
- Universal Or Specific Fit: Universal
- Wattage Draw @ 12V DC: Driving Light - 39 Watts, Position - 1.8 Watts
- Weight: 2.42 LBS
- Width: 4.1 IN.
- Wire Quantity: 3
- Wiring Harness Included: Y
