Description
Accessory Control Redefined with PROJECT X Ghost Box Wireless Ecosystem
Revolutionize your vehicle’s accessory control with the PROJECT X Ghost Box wireless ecosystem. This system redefines the market standard for switch boxes by providing a fully customizable and wirelessly controlled experience.
Qualifies for free shipping
The expandable system includes four two-circuit control modules that wirelessly communicate with a control keypad, which you can easily program using the PROJECT X app.
Whether you want to control a single module for a simple accessory install or create a large system for your vehicles, trailers, and equipment, the Ghost Box makes it possible.
Furthermore, you can create presets, set timers, create lighting scenes, and much more, making it the perfect solution to Connect with the Wild.
Fully Customizable Ecosystem
With the PROJECT X Ghost Box, you can create a customizable ecosystem tailored to your needs. Using the PROJECT X app, you can set up lighting scenes, preset colors, control groups, timers, and other features, all in a few taps. As a result, you have full control over your accessories, making it easier than ever to manage them.
Make Any Accessory Smart
Turn any accessory into a smart device by adding a Ghost Box control module to its power harness. This seamlessly integrates the accessory into the PROJECT X ecosystem, allowing you to control it wirelessly. In addition, this means you can access all your accessories through a single, cohesive platform, simplifying your setup.
Wireless Control for Ultimate Freedom
The Ghost Box control modules connect wirelessly to your control pad via 2.4GHz RF Wireless, eliminating the need to route wires into your cab. Simply tap the control pad, and you’re ready to go—no more fussing with complex wiring. Thanks to the wireless setup, you enjoy both convenience and flexibility while maintaining full control.
Wired Reliability, Wireless Freedom
While wireless control is the key benefit, the Ghost Box system still provides wired reliability using both Bluetooth and RF Wireless technology. This hybrid connection ensures that your control remains uninterrupted, even when you’re out in the wild.
Dual Circuit for Versatility
Each Ghost Box control module is equipped with a 2-circuit setup, offering 20 amp and 40 amp circuits for versatile accessory control. This dual circuit design provides you with multiple options, making it easy to control accessories of different power needs.
Easy to Pair and Expand
Pairing is intuitive! Connect your vehicle accessories just like syncing any Bluetooth product to integrate them into your PROJECT X ecosystem. Additionally, the system allows you to expand your control by adding up to 24 control modules, linking your vehicle, trailers, and other equipment for a unified control system.
- Circuit Terminal Gender: Female
- Circuit Terminal Quantity (Per Module): 6 Terminals: Input Positive, Input Negative, Output 1 Positive, Output 1 Negative, Output 2 Positive, Output 2 Negative,
- Circuit Terminal Type: Screw Terminal
- Connector Quantity (Keypad): 1
- Connector Type (Keypad): RJ45
- Control Method: Keypad or App (IOS & Android)
- Hardware Included: Yes
- Hardware Material: Stainless
- Height - Control Module with Antennas: 6.3 IN
- Height - Control Module without Antennas: 1.4 IN
- Height - Keypad: 2.9 IN
- Input Voltage Range: 9-16V DC
- Keypad Included: Yes
- Keypad Wiring Harness Included: Y
- Length - Control Module: 6.7 IN
- Length - Keypad: 2.9 IN
- Maximum Current (Keypad): 0.075 Amps @ 12V DC
- Maximum Wattage (Keypad): 0.9 Watts @ 12V DC
- Maximum Wire Size: 8 AWG
- Mounting Hole Quantity: 2 per Module
- Number of Circuits (Per Module): 2
- Number of Circuits (Total): 8
- Operating temperature: -22F to 149F
- Output Maximum Current (Control Module): Circuit 1: 20 Amps @ 12V DC, Circuit 2: 40 Amps @ 12V DC
- Output Maximum Wattage (Control Module): 480 Watts @ 12V DC
- Storage Temperature: -40F to 185F
- TLE: PROJECT X - Ghost Box (1 Keypad + 4 Modules)
- Universal Or Specific Fit: Universal
- Waterproof Rating: IP64
- Weight - Keypad: 0.5 LBS
- Weight - Per Control Module: 0.5 LBS
- Width - Control Module: 3.4 IN
- Width - Keypad: 0.7 IN
- Wireless Frequency: 2.4GHz RF Wi-Fi & Bluetooth 5.0
- Wireless Range (Bluetooth): 33 Feet without interference or obstruction
- Wireless Range (RF Wi-Fi): 98.4 Feet without interference or obstruction
